Automatic Alloy Aluminum Ring Strip Coiling And Butt Welding Machine

  • 1
  • 2
  • 3

Brand Name : HWASHI

Model Number : WL-AT-75K

Certification : CE/CCC/ISO

Place of Origin : China

MOQ : 1 set

Price : negotiation

Payment Terms : L/C, T/T

Supply Ability : 50 sets per month

Delivery Time : 7-30 working days after received your payment

Packaging Details : sea worthy wooden package

Product Name : Automatic Alloy Aluminum Ring Strip Coiling And Butt Welding Machine

Application : Suitable for welding metals

Size : 1800mmX1400mmX1400mm

Weight : 1100 kg

Condition : New

Warranty : one year

Standard : CE/CCC/ISO

Service Life : 8-10 years

Welding range : Automatic ring coiling and butt welding

Welding thickness : 4+4mm

Contact Now

Automatic Ring Coiling And Butt Welding Machine , Alloy Aluminum Welding Machine

Descrpition
This automatic ring making and welding machine is composed of automatic feeding, automatic coiling, automatic moving, automatic welding and automatic unloading process.

Feature

Technological process:

  1. Automatic feeding ( feeding the wire)
  2. Automatic coiling ( hydraulic system, wire pressing wheel)
  3. Automatic moving (cylinder robot arm)
  4. Automatic welding (AC pulse power/MF DC power)
  5. Automatic unloading (cylinder robot arm)
  6. Sound-light alarm function: the machine will give alarm when the material is used up, the power is overpressure, the welding current is abnormal or when the temperature is too high.
  7. Counting function: the machine will sum up the number of qualified product, defective product and welding times of electrode.
  8. Monitoring function: the display screen will monitor the whole process of actions and the welding current of each welding process. It will give alarm when the monitoring function is abnormal.



SPECIFICATION

No. Item Automatic Welding Automatic Welding Automatic Coiling
1 Input Power 75KW 75KW 2.2KW
2 Input Voltage

400V50Hz

Three-phase

400V50Hz

Single-Phase

 380V Three-Phase
3 Input Current 115A 135A 10A
4 Output Voltage DC7.6V AC5.6V
5 Max Short Circuit Current 21000A 24000A
6 Welding Models 101 types 16 Types
7 Wire Diameter Range 2-8mm
8 Coiling Ring Diameter 35-750mm
9 Feed Rate 20m/Min
10 Robotic Arm Moving Speed 500mm/Sec
11 Robotic Arm Open Distance 10mm
12 Welding Cylinder ￠100x80mm
13 Moving Cylinder ￠32x100mm
14 Clamping Cylinder ￠16x20mm

APPLICATION
Mainly used to butt welding of key,low-carbon steel ,copper ,brass,stainless steel ,aluminum and other metal wires.
Automatic Alloy Aluminum Ring Strip Coiling And Butt Welding MachineAutomatic Alloy Aluminum Ring Strip Coiling And Butt Welding Machine


COMPETITIVE ADVANTAGE
1. HWASHI is the leading brand in resistance welding industry in China for 20 years; Factory direct sale, competitive price.
2. Customized Service: We can help to design and develop the welding machine according to your requirement. We are flexible and capable Supplier.
3. Genuine Product with Excellent Quality: 12 months warranty. Our machines are strictly complied with ISO9001:2000 and China Compulsory Certification. Most of our machines enjoy 8-10 years service life. 100% guarantee test before delivery.
4. After Sales Service and Technical Assistance: 24 hours technical support by email. Our professional team is always here willing to be your technical consultant.
5. Quick Delivery: Our company provides just-in-time delivery.
6. Prompt Response to Customers: Your satisfaction is the goal we pursue.



Automatic Alloy Aluminum Ring Strip Coiling And Butt Welding Machine

Automatic Alloy Aluminum Ring Strip Coiling And Butt Welding Machine
